ATH Cross Lift® 40 Plus OGA
Experience every detail – rotate, zoom and explore interactively.
Experience every detail – rotate, zoom and place the model in your real environment with AR.
The ATH Cross Lift® 40 Plus OGA is a high-quality Drive one platform lift with a 4,000 kg capacity and hydraulic drive, designed to require minimal maintenance. It features recesses for turntables, pneumatically lockable slip plates, extended platforms with joint play tester, and a free-wheel lift with a 4 t capacity. Pneumatic safety locks, CE stop, acoustic lowering signal, integrated 24 V LED lighting and the included on-ground installation kit make it ideal for reception, wheel alignment, repair and testing bays for headlight and driver assistance systems.
Product highlights
High-quality and robust hydraulic drive platform scissor lift with minimal maintenance requirements
Powerful hydraulic unit with load-dependent lowering valve
Suitable for mounting on the ground with the above-ground kit
With recesses for turntables at the front, mechanically lockable swing plates at the rear, wheel-free jack (load capacity: 4 t, lifting height: 450 mm), running rails for the optional axle-free jack, plug-in cross connections, incl. metal guard and switch for the optional 24V LED lighting
Pneumatic unlocking of the safety catches, CE stop and signal tone when lowering
Emergency lowering system for lowering in the event of a power failure, synchronisation monitoring via light barrier
Ideally suited for reception, wheel alignment, repair and test station for headlight and driver assistance systems
Product details
| Rated load capacity | 4000 kg |
|---|---|
| Lifting height max. | 2160 mm |
| Overall height | 295 mm |
| Driving power | 3,5 kW |
| Lifting/Lowering time | 70 | 70 s |
| Power supply voltage | 3x 400V / C16A |
| Concrete strength | C20/25 6100 x 3000 x 200 |
| Color | RAL 7016 / RAL 9005 |
| Drive-on-height | 295 mm |
| Total platform length | 4830 mm |
