ATH Cross Lift® 40 UGA
Experience every detail – rotate, zoom and explore interactively.
Experience every detail – rotate, zoom and place the model in your real environment with AR.
The ATH Cross Lift® 40 UGA is a Drive one platform lift requiring minimal maintenance, with a 4,000 kg capacity and hydraulic drive. Recesses for turntables, mechanically lockable slip plates and a free-wheel lift (4 t / 450 mm) support service and wheel alignment. Rails for an optional Rolling Jack, plug-in cross connections and metal protection bars with switch for optional 24 V LED lighting complete the equipment. Pneumatic safety locks, CE stop and an acoustic lowering signal.
Product highlights
High-quality and robust hydraulic drive platform scissor lift with minimal maintenance requirements
Powerful hydraulic unit with load-dependent lowering valve
Suitable for floor-level installation and installation on the ground with optional above-floor kit
With recesses for swivel plates at the front, mechanically lockable swing plates at the rear, wheel-free jack (load capacity: 4 t, lifting height: 450 mm), runners for the optional axle-free jack, pluggable cross-connections, incl. metal safety guard and switch for the optional 24V LED illumination
Pneumatic release of the safety catches, CE-Stop and signal tone when lowering
Emergency lowering system for lowering in case of power failure, synchronisation monitoring via light barrier
Ideally suited for acceptance, wheel alignment, repair and test station for headlamp and driver assistance systems
Product details
| Rated load capacity | 4000 kg |
|---|---|
| Lifting height max. | 2160 mm |
| Overall width | 2140 mm |
| Overall height | 290 mm |
| Driving power | 3,5 kW |
| Lifting/Lowering time | 70 | 70 s |
| Power supply voltage | 3x 400V / C16A |
| Color | RAL 7016 / RAL 9005 |
| Total platform length | 4230 mm |
| Installation depth | 295 mm |
