LED Kit for ATH Comfort Lifts (1 set = 4 pieces)

This specially developed LED kit is the perfect addition to all ATH Comfort Lifts. Thanks to its slim construction and well-designed layout, the kit is installed discreetly behind the support arm sections of the lift. The LEDs are integrated into slim aluminium profiles and wired directly to the lift, allowing convenient operation via the lift’s control panel – including a dimming function and ON/OFF control.

Technical data:

LED density

Total number of LEDs (4 profiles): 2,736 LEDs

Input voltage: 12 V DC

Light output:

4 profiles (total): 60,192–71,136 lumens

Power consumption:

4 profiles (total): 547.2 W

Colour temperature:

6000 K (pure white) – for clear and uniform illumination.

Special features:

Suitable for all ATH Comfort Lifts: Developed for perfect integration into the lift.

Ultra-slim aluminium profile: Enables discreet installation behind the support arms of the lift.

Direct wiring: The LEDs are connected directly to the lift, allowing convenient control via the control panel.

Dimmable: Adjust the light intensity to suit your requirements.

Switchable ON/OFF: Convenient operation directly from the lift.

Robust and durable: The aluminium profiles protect the LEDs and ensure optimum heat dissipation.

High efficiency: Maximum brightness with low power consumption.

Scope of delivery:

4 aluminium profiles with pre-installed LED strips

Total length of the kit: 2.85 m

Ready for direct connection to the ATH Comfort Lift.

With this LED kit, you can transform your ATH Comfort Lift into a perfectly illuminated workstation. The ideal combination of functionality, efficiency and design for professional workshop applications!
